Competitive price fiber optic cable types outdoor GYXY aerial ftth drop fiber cable

Description
 Non-Armored Uni-Tube optical cable with fibers placed in loose buffer tube.The cable core is protected with jelly to prevent water intrusion and migration, and coverwith a black polyethylene out jacket. Two embedded FRP or metallic wire provide desire tension.

Feature
Competitive Price Fiber Optic Cable Types Outdoor GYXY Aerial FTTH Drop Fiber Cable
Competitive Price Fiber Optic Cable Types Outdoor GYXY Aerial FTTH Drop Fiber CableCompetitive Price Fiber Optic Cable Types Outdoor GYXY Aerial FTTH Drop Fiber Cable

 Features
Embedded strength member provide desirable tensile strength.
Compact, easy to install.
UV and moisture-resistant design


 Applications
Installed in duct, direct burial.
FTTx.

 Optical Charateristics

Fiber Type

G.652

G.655

50/125^m

62.5/125^m

Attenuation

(+20X)

850 nm





<3.0 dB/km

<3.3 dB/km

1300 nm





<1.0 dB/km

<1.0 dB/km

1310 nm

<0.36 dB/km

<0.40 dB/km





1550 nm

<0.22 dB/km

<0.23 dB/km





Bandwidth

850 nm





>500 MHz-km

>200 Mhz-km

1300 nm





>500 MHz-km

>500 Mhz-km

Numerical Aperture





0.200±0.015 NA

0.275±0.015 NA

Cable Cut-off Wavelength cc

<1260 nm

<1450 nm





 Structure and  Technical Specifications                                                GYXY

Fiber

Count

Nominal

Diameter

(mm)

Nominal

Weight

(kg/km)

Allowable Tensile Load

                (N)

Allowable Crush Resistance
               (N/100mm)

Short Term

Long Term

Short Term

Long Term

2~12

6.2

52

1000

400

1000

1000

14~24

7.0

64

1200

500

1000

1000

 Structure and  Technical Specifications                       GYFXY(All-Dielectric)

Fiber

Count

Nominal

Diameter

(mm)

Nominal

Weight

(kg/km)

Allowable Tensile Load

                (N)

Allowable Crush Resistance
               (N/100mm)

Short Term

Long Term

Short Term

Long Term

2~12

6.2

45

600

250

1000

1000

14~24

7.0

56

800

300

1000

1000

Note : This datasheet can only be a reference, but not a supplement to the contract. Please contact our sales people for more detailed information.
